Kinze 3600 Lift and Rotate Planter Rev. 5/14 - Manual (Page 199)

Electrical Components
ITEM PART NO. QTY. DESCRIPTION
5 GA9096 - Harness Extension, 42"
6 GD8739 - Sealing Plug, No. 12
7 GD8740 - Socket Contact, No. 14
8 GD8741 - Pin Contact, No. 14
9 GA9202
GA9204
GA5385 -
-
- Wiring Harness W/7 Terminal Female Connector, 786" (2 Light Connections), 12 Row 30"
Wiring Harness W/7 Terminal Female Connector, 882" (2 Light Connections), 16 Row 30"
7 Terminal Female Connector
10 GA6109 1 Connector W/Cable Clamp, 23 Pin Capacity
11 GA7862 - Dust Cap W/Chain
12 GA7863 - Dust Cap W/Chain
13 GA6108 1 Connector W/Cable Clamp, 23 Socket Capacity
14 G1K248 - 3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
15 G1K252 - 3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
16 GD11089 - Sealing Plug
17 GA8047 - Dust Plug (Black)
18 GA16338
GA16339 1
-
3600 Planter Cable, 12 Row 30"
3600 Planter Cable, 16 Row 30"
19 GA11736 - Harness Extension W/Dust Caps, 180"
20 GA7077 1-4 Indicator Light
21 GA2612 3-5 Fuse Holder W/Spade, 133∕50"
22 GD2829 1-2 Fuse, 15 Amp, Type AGC
23 GD10243 2-6 Fuse, MDL 10 Amp Delay Action
24 GR1363
GR1364 5
5 Hex Face Nut, 15∕32"-32
Internal Tooth Lock Washer, 15∕32"
25 GA8734
GA8735 1
-
Cover Plate (Shown)
Cover Plate, Planters Equipped With Two-Speed Point Row Clutch
26 GR1292 4 Pan Head Screw, No. 8-32 x ½"
27 GD3860 - O-Ring (If Applicable)
28 GA2528 2 Switch, 3 Position Toggle, On-Off-On
29 GA6978 2 Switch, 3 Position Toggle, Momentary On-Off-Momentary On
30 GA6977 1-2 Switch, 2 Position Toggle, On-Off
31 GA8731 1 Switch, Push Button W/Transformer
32 GD9896 1 Mounting Bracket
33 G11385 4 Flat Washer, ¼" SAE
34 GA6975 2 Knob
35 GR1290 2 Cage Nut, ¼"-20
36 G1K267 - Console Cable Connector Kit, Includes: (1) 3-Pin Connector, (1) Cable Clamp, (3)
Male Terminal Pins
37 G1K268 - Console Cable Connector Kit, Includes: (1) 3-Pin Connector, (1) Cable Clamp, (1)
Lock Ring, (3) Female Terminal Pins
38 GA17547 1 Power Adapter Cable
39 GA16340 1 Control Box Cable
40 G7633X - Backlit Control Console Assembly W/Mounting Brackets, Short Harness W/Dust Cap
And Power Cable
G7639X - Backlit Control Console Assembly W/Mounting Brackets, Short Harness W/Dust Cap
And Power Cable (Planters Equipped With Two-Speed Point Row Clutch)
41 GD22965
GD6291
GD13348 -
-
- Insulated Clamp, ¼"
Insulated Clamp, ⅜"
Insulated Clamp, 11∕16"
42 GD13310 - Jumper, 7∕16"
43 GA9481
G10996 -
- Jumper Wire W/Fork Terminal, 13"
Fork Terminal
44 GA10924
GA5385 1
-
Wiring Harness, 348"
7 Terminal Female Connector
45 G1K320 - 2-Pin Male Connector Kit (Black), Includes: (3) 2-Pin Male Housings, (6) Socket
Contacts, (6) Seals
46 G1K321 - 2-Pin Female Connector Kit (Black), Includes: (3) 2-Pin Female Housings, (6) Pin
Contacts, (6) Seals
NOTE: See “Point Row Clutch” on page P139 or See “Two-Speed Point Row Clutch” on page P141 for R.H. and L.H. Wiring
Harness for the point row clutches. See “KPM III Electronic Seed Monitor” on page P197 for those components.
Model 3600 M0236-02
Rev. 5/13 P196
TM
