Kinze 3600 Lift and Rotate Planter Rev. 5/14 - Manual (Page 202)

KPM III Electronic Seed Monitor
ITEM PART NO. QTY. DESCRIPTION
30 G1K252
G1K363
-
-
3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
3-Pin Male Connector Kit (Blue), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
31 GD11089 - Sealing Plug
32 G1K249 - Acre Counter Switch Kit
33 GA8046
GA9978 -
- Dust Plug (Black)
Dust Plug (Blue)
34 GA8047
GA9979 -
- Dust Plug (Black)
Dust Plug (Blue)
35 G10686
G10229
G10101 4
4
4 Hex Head Cap Screw, ⅜"-16 x 8"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
36 GR1415 1 Rotation Sensor
37 G11288
G10243
G10758 2
2
2 Pan Head Screw, No. 10-32 x 1¼"
Washer, No. 10 SAE
Hex Nut, No. 10-32
38 GD11474 2 Cover
39 G10927
G10931
G10928 2
2
2 Pan Head Machine Screw, No. 8-32 x 1¼", Stainless Steel
Lock Washer, No. 8, Internal/External, Stainless Steel
Hex Nut, No. 8-32, Stainless Steel
40 GR1414 1 Actuator
A GA6147 - Magnetic Distance Sensor And Mounting Package (Items 4-9)
B GR1763 - KPM III Loaner (Display Only)
C GA13521 - Shaft Sensor Mounting Package (Items 10, 21, 35, and 37-39)
D GA8135 - Shaft Rotation Kit, Includes: (2) Actuators (2) Rotation Sensors
TM
M0236-02 Model 3600
P199 Rev. 7/11
