Kinze 3600 Lift and Rotate Planter Rev. 5/14 - Manual (Page 147)

ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 GD5857 2 Spring
2 G10602 3 Spring Pin, ¼" x 1½"
3 GA5109
GA5105
GA5106
GA5112
GA5108
GA5110
GA5111 1
1
1
1
-
-
-
Sprocket, 24 Tooth
Sprocket, 15 Tooth
Sprocket, 17 Tooth
Sprocket, 27 Tooth
Sprocket, 23 Tooth (From Transmission)
Sprocket, 25 Tooth (From Transmission)
Sprocket, 26 Tooth (From Transmission)
4 GA5113 1 Sprocket, 28 Tooth
5 G10233 - Machine Bushing, 1", 10 Gauge
6 G3400-01 - Flangette
7 G2100-03 - Bearing, ⅞" Hex Bore, Spherical
8 G10312
G10232
G10106 6
6
6 Carriage Bolt, 5⁄16"-18 x ¾"
Lock Washer, 5⁄16"
Hex Nut, 5⁄16"-18
9 GD10355 1 Shaft, ⅞" x 13¾"
10 GA7306 1 Extension Bracket
11 G10857
G11385
G10227
G10103 2
2
2
2 Hex Head Cap Screw, ¼"-20 x 1¼"
Flat Washer, ¼" SAE
Lock Washer, ¼"
Hex Nut, ¼"-20
12 G10408
G10409 1
1 Clevis Pin, 5⁄16" x ¾"
Retaining Ring, 5⁄16"
13 G10064
G11385
G10227
G10103 2
2
2
2 Hex Head Cap Screw, ¼"-20 x 1"
Flat Washer, ¼" SAE
Lock Washer, ¼"
Hex Nut, ¼"-20
14 --- - See “Contact Wheel and Drive Shaft(s)” on page P131
15 --- - See “Two-Speed Point Row Clutch” on page P141
16 G3310-74
GR0912 2
-
Chain, No. 40, 74 Pitch Including Connector Link
Connector Link, No. 40
17 G3310-100
GR0912 1
-
Chain, No. 40, 100 Pitch Including Connector Link
Connector Link, No. 40
18 GA7320
GA7321
G10430
GD1255
G10546
G10470
GD10366
GA7317
GA7319 1
-
1
6
6
6
6
1
1
Overrunning Sprocket Assembly, R.H.
Overrunning Sprocket Assembly, L.H.
External Retaining Ring, 1¼"
L-Pin
Spring Pin, 3⁄16" x 1¼"
Cotter Pin, 5⁄32" x 1"
Spring
Block
Sprocket W/Bushing, 30 Tooth
19 GD10543 1 Hex Shaft, ⅞" x 13"
20 GA9918
GD10356
G10128
G10501
G10053
GA7154 1
-
-
-
-
-
Idler W/Sprocket And Hardware
Bushing, ¾" Long
Machine Bushing, ½", 14 Gauge
Hex Jam Nut, ½"-13, Grade 2
Hex Head Cap Screw, ½"-13 x 2 ½"
Sprocket W/Bearing, 18 Tooth
Two-Speed Point Row Clutch Wheel Module Extension
Model 3600 M0236-02
Rev. 7/11 P144
