ITEM PART NO. QTY. DESCRIPTION
1 GD18112
G10992
G11066
1
4
4
Cover
Serrated Flange Nut, No. 10-24
Phillips Pan Head Machine Screw, No. 10-24 x ¾", Stainless Steel
2 GA14127
GR1943
GA12404
GR1809
1
-
-
-
Filter Assembly (2010 production and on)
Filter (2010 production and on)
Filter Assembly (prior to 2010 production)
Filter (prior to 2010 production)
3 GA12102
G10992
G11066
1
4
4
Air Compressor
Serrated Flange Nut, No. 10-24
Phillips Pan Head Machine Screw, No. 10-24 x ¾", Stainless Steel
4 GA12358
G10019
G10232
G11386
G10106
1
4
4
4
4
Compressor Mount
Hex Head Cap Screw, 5∕16"-18 x 1"
Lock Washer, 5∕16"
Flat Washer, 5∕16" SAE
Hex Nut, 5⁄16"-18
5 GD4743
G10228
G10102
2
4
4
U-Bolt, 3" x 3" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
6 GD18119 2 Compressor Mount
7 G10106
G10232
G11386
G10019
4
4
4
4
Hex Nut, 5⁄16"-18
Lock Washer, 5⁄16"
Flat Washer, 5∕16" SAE
Hex Head Cap Screw, 5⁄16"-18 x 1"
8 GA11988 1 Tank, 3 Gallon
9 GA13512 1 Valve Stem, ¼" NPT
10 GD19237 2 Tee, ¼" NPT
11 GD17156 3 Plug, ¼" NPT
12 GD19238 2 Nipple, ¼" NPT
13 GR1778 1 Pressure Switch
14 GA11991 1 Drain, ¼" NPT
15 GR1951 1 Leader Hose without Check Valve
16 GR1921 1 Check Valve
17 GD18084
G10023
G10227
G10103
1
2
2
2
Regulator Bracket
Hex Head Cap Screw, ¼"-20 x ¾"
Lock Washer, ¼"
Hex Nut, ¼"-20
18 GA12629
GD19124
1
2
Mini Regulator W/Gauge
Connector, ¼" x ⅛" NPT
19 GA12104 1 Pressure Gauge, ¼" NPT
20 GD17141 2 Connector, ¼" Male NPT
21 GD18078 1 Female Cross, ¼" NPT
22 GD17154 1 Connector, ¼" Male NPT
23 G10021
G10227
2
2
Hex Head Cap Screw, ¼"-20 x 1½"
Lock Washer, ¼"
24 GA11993 1 Block
25 GD17156 2 Plug, ¼" NPT
26 GD17143 1 Swivel Elbow, ¼" NPT x ⅜"
27 GA11997 1 Breather, ¼" NPT
28 GR1952
GR1953
G10256
4
4
4
Socket Head Cap Screw, #8-32 x 2"
O-Ring
Lock Washer, No. 8
29 GA11994
G11311
2
4
Solenoid
Phillips Pan Head Machine Screw
30 GA11992 1 Shutoff Valve, ¼" NPT
A GA12626 - Air Compresor Assembly (Items 1-4, 8-14, and 25)
B GA11995 - Dual Solenoid Assembly (Items 19-22 and 24-30) (Only applicable with pneumatic
down pressure option)
C GR1783 - Seal Kit (Dual Solenoid Valve)
Air Compressor, Dual Solenoid Assembly, Tubing, and Fittings
Model 3600 M0236-02
Rev. 7/12 P152
