Inner Hitch, “Y”
ITEM
PART NO.
QTY.
DESCRIPTION
1
A14309
A14307
A17087
1
-
-
Inner Hitch, 175⅜", 12 Row 30" (Shown)
(Non-Stock Item)
Inner Hitch, 205⅜", 16 Row 30"
(Non-Stock Item)
Inner Hitch, 205⅜", 16 Row 7.5" Twin Row
(Non-Stock Item)
2
GA7424
G10641
1
-
Tongue Hook W/Grease Fittings Grease Fitting, ⅛" NPT
Grease Fitting, ⅛" NPT
3
GD5804
GD7883
G10468
1
1
2
Pin, 1¼" x 12", 12 Row
Pin, 1¼" x 14½", 16 Row
Cotter Pin, ⅜" x 2"
4
GD8189
3
Rubber Strip, ⅜"
5
GD8188
3
Hose Clamp, ⅞" x 3" x 5⅜"
6
G11387
2
Flat Washer, ⅜" SAE
7
G10108
2
Lock Nut, ⅜"-16
8
G10111
1
Lock Nut, ½"-13
9
G10437
G10436
4
4
Hex Head Cap Screw, ¾"-8 x 2½", Grade 8
Hex Nut, ¾"-10
10
G10808
G11394
G10647
6-8
8-10
6-8
Hex Head Cap Screw, 1"-8 x 10", Grade 8
Flat Washer, 1" SAE
Hex Nut, 1"-8, Grade 8
11
GD5875
1
Hose Clamp, 9∕16" x 2½" x 2"
12
G10101
1
Hex Nut, ⅜"-16
13
GD10530
G10101
G11091
1
2
2
U-Bolt, 2⅛" x 1⅞" x ⅜"-16
Hex Nut, ⅜"-16
Serrated Flange Nut, ⅜"-16
14
GD10538-01
G11389
G10585
G10071
1
5
1
1
Sleeve
Flat Washer, ½" SAE
Hex Head Cap Screw, ½"-13 x 3¼"
Serrated Flange Nut, ½"-13
15
G6400-06-08
GR1037
2
-
Connector W/O-Ring, 9∕16"-18 Male JIC To ¾"-16 O-Ring
O-Ring
16
GA9205
1
See “Tongue Lock Cylinder” on page P165
17
GD3537-20
G11230
1
2
Shaft, 1¼" x 7⅛"
Retaining Ring
18
GA13938
1
See “Tongue Cylinder” on page P167
G6400-08
GR1037
1
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
19
GD0826
G10460
1
2
Pin, 1¼" x 5½"
Cotter Pin, ¼" x 2"
20
GB0246
GD3537-11
GD3537-12
G10131
1
1
1
1
Hitch Shoe
Shaft, 1¼" x 7", 12 Row 30"
Shaft, 1¼" x 8", 16 Row 30"
Square Head Set Screw, 5∕16"-18 x ¾"
21
GD9959
GD5154
G10014
G10017
G11389
2
4
4
Wear Pad, Nylatron, 4" x 4"
Shim, 4" x 4"
Hex Head Cap Screw, ½"-13 x 1", 12 Row 30"
Hex Head Cap Screw, ½"-13 x 1½", 16 Row 30"
Flat Washer, ½" SAE, 16 Row 30"
22
G10062
G10048
2
-
Hex Head Cap Screw, ⅜"-16 x 3" (EdgeVac/ASD)
Hex Head Cap Screw, ⅜"-16 x 2" (Mechanical/ASD)
23
GD21746
2
Hose Clamp
24
GD11963-08
2
Tube, ½" O.D. x 2"
25
GD23020
2
Hose Clamp
26
GD18116
-
Roatation Bracket
Model 3600
