Dry Fertilizer Drive
ITEM PART NO. QTY.
(Per Side)
DESCRIPTION
12 GD10119 1 Shaft, ⅞" x 77∕16"
13 GD5857 2 Spring
14 G10640 2 Grease Fitting, ¼"-28
15 --- - See “Dry Fertilizer Coupler/Shafts” on page P229
16 GA5116 3 Bearing, ⅞" Hex Bore, Cylindrical
17 G10233 2 Machine Bushing, 1", 10 Gauge
18 GD3180-10 1 Sleeve, ⅝" I.D. x ⅞" O.D. x 3¼" Long
19 GD2734-08 1 Sleeve, 1 ¼" O.D. x ⅝" Long
20 G10017
G11389
G10228
G10102 2
4
2
2 Hex Head Cap Screw, ½"-13 x 1½"
Flat Washer, ½" SAE
Lock Washer, ½"
Hex Nut, ½"-13
21 G3310-130
GR0912 1
-
Chain, No. 40, 130 Pitch Including Connector Link
Connector Link, No. 40
22 GA5114 1 Sprocket, 30 Tooth
23 G10419
G11389
G10111 1
1
1 Carriage Bolt, ½"-13 x 4½"
Flat Washer, ½" SAE
Lock Nut, ½"-13
24 GA7396
GD7426
GD1026
G11387
G10229
G10047
G10049
G10108 1
-
-
-
-
-
-
-
Idler W/Bolt-On Sprockets
Sprocket, 12 Tooth
Sleeve, 13∕16" Long
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Head Cap Screw, ⅜"-16 x 1¾"
Hex Head Cap Screw, ⅜"-16 x 2½"
Lock Nut, ⅜"-16
25 GD1134
G10230
G10104 2
4
4 U-Bolt, 7" x 5" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
26 GA7129
GA7130 1
-
Mount, L.H. (Shown)
Mount, R.H.
27 GA5671
GA5672 1
-
Transmission Plate, L.H. (Shown)
Transmission Plate, R.H.
28 GD14413
GD14414 -
1
Torsion Spring, L.H. (Used In R.H. Wrap Spring Wrench) (Shown)
Torsion Spring, R.H. (Used In L.H. Wrap Spring Wrench)
29 GD14431 1 Handle
30 G11100
G10227
G11453 1
1
1 Hex Socket Button Head Cap Screw, ¼"-20 x ½", Grade 8
Lock Washer, ¼"
Fender Washer, ¼"
31 G11075 2 External Inverted Snap Ring, ⅞"
32 G10496 2 External Inverted Snap Ring, 1½"
33 GD14427 1 Tightener Shaft, 4⅞"
34 G11078 1 Vinyl Cap
35 GD14432 1 Sleeve, 1¼"
36 GD19343
GD19344 1
-
Release Collar, Gold, R.H. (Shown)
Release Collar, Silver, L.H.
37 GA12192 1 Sprocket, 22 Tooth
38 GD26025 - Bulkhead Mount
39 GD26024 - Bulkhead Mount
A G1K378
G1K379 1
-
Wrap Spring Wrench Replacement Kit, Blue Collar, R.H. (Items 28-36) (Shown)
Wrap Spring Wrench Replacement Kit, Gray Collar, L.H. (Items 28-36)
