Kinze 3600 Lift and Rotate Planter Rev. 5/14 - Manual (Page 71)

ITEM PART NO. QTY. DESCRIPTION
1 --- - See “Vacuum Fan Hydraulic Motor Assembly” on page P181
2 --- - See “Valve Blocks - Located on R.H. Rear Center Frame” on page P173
3 --- - See “Vacuum Fan Motor Valve Block Assembly (Located Below Vacuum Fan Motor
Assembly)” on page P182
4 *A12002 1 Hose Assembly, ⅜" x 32"
5 *A1424 1 Hose Assembly, ½" x 30"
6 *A3381 1 Hose Assembly, ¾" x 26"
7 G6502-12 1 Swivel Elbow, 45°, 11⁄16"-12 Male JIC To Female
8 G6500-06 1 Swivel Elbow, 90°, 9∕16"-18 Male JIC To Female
9 G6500-10 1 Swivel Elbow, 90°, ⅞"-14 Male JIC To Female
10 G6701-12 1 Elbow, 90°, 11⁄16"-12 Male JIC To Female
11 *A12093 1 Hose Assembly, ⅜" x 58"
12 *A12753 1 Hose Assembly, ½" x 57"
13 *A11444 1 Hose Assembly, ⅝" x 59"
14 G6400-06
GR1045 1
-
Connector W/O-Ring, 9∕16"-18 Male JIC To O-Ring
O-Ring
15 G304-C-10 1 Cap Nut, ⅞"-14
16 G304-C-12 1 Cap Nut, 11⁄16"-12
17 *A12094 1 Hose Assembly, ⅜" x 73 "
18 *A1464 1 Hose Assembly, ½" x 72"
19 *A11443 1 Hose Assembly, ⅝" x 73"
20 G2700-06-06
G306-06 1
1 Bulkhead Tube Union, 9∕16"-18 Male JIC
Lock Nut, 9∕16"-18
21 G2700-10
G306-10 1
1 Bulkhead Tube Union, ⅞"-14 Male JIC
Lock Nut, ⅞"-14
22 G2700-12
G306-12 1
1 Bulkhead Tube Union, 11⁄16"-12 Male JIC
Lock Nut, 11⁄16"-12
23 *A12096
*A15023 1
-
Hose Assembly, ⅜" x 140", 12 Row 30" and 16 Row 30"
Hose Assembly, ⅜" x 154", 16 Row 7.5" Twin Row
24 *A12751
*A12774 1
-
Hose Assembly, ½" x 142½", 12 Row 30" and 16 Row 30"
Hose Assembly, ½" x 157", 16 Row 7.5" Twin Row
25 *A11442
*A11458 1
-
Hose Assembly, ⅝" x 137½", 12 Row 30" and 16 Row 30"
Hose Assembly, ⅝" x 152", 16 Row 7.5" Twin Row
26 G2702-06
G306-06 1
1 Bulkhead Elbow, 45°, 9∕16"-18 Male JIC
Lock Nut, 9∕16"-18
27 G2702-10
G306-10 1
1 Bulkhead Elbow, 45°, ⅞"-14 Male JIC
Lock Nut, ⅞"-14
28 G2702-12
G306-12 1
1 Bulkhead Elbow, 45°, 11⁄16"-12 Male JIC
Lock Nut, 11⁄16"-12
29 *A12086
*A12087 1
-
Hose Assembly, ⅜" x 206", 12 Row
Hose Assembly, ⅜" x 266", 16 Row
30 *A12754
*A8266 1
-
Hose Assembly, ½" x 206", 12 Row
Hose Assembly, ½" x 268", 16 Row
31 *A11449
*A11450 1
-
Hose Assembly, ⅝" x 206", 12 Row
Hose Assembly, ⅝" x 266", 16 Row
32 *A12092
*A12091 -
- Hose Assembly, ⅜" x 127", 12 Row
Hose Assembly, ⅜" x 187", 16 Row
33 GA15499
GD25522 -
- Special Pioneer Coupler, Zero Pressure Return
Hydraulic Tip Cover
34 GD4086 - ISO Coupler
* Hydraulic hose is not stocked by Kinze Repair Parts, but can be made available on a special order basis.
Call for quote.
Vacuum Fan Hydraulic Components
Model 3600 M0236-02
Rev. 5/13 P68
