Seed Rate Transmission and Row Unit Drill Shafts
ITEM
PART NO.
QTY.
(Per Side)
DESCRIPTION
18
GA7336
GD7426
G10047
GD1026
G11387
G10229
1
-
-
-
-
-
Idler W/Bolt-On Sprockets
Sprocket, 12 Tooth
Hex Head Cap Screw, ⅜"-16 x 1¾"
Sleeve, 13∕16" Long
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
19
GD7612
1
Shaft, ⅞" x 13½"
20
G10303
G10620
-
-
Carriage Bolt, 5∕16"-18 x 1"
Hex Nut, 5∕16"-18
21
GA5548
1
Special Bearing
22
G3400-01
-
Flangette
23
G2100-03
-
Bearing, ⅞" Hex Bore, Spherical
24
GA8092
1
Clutch Sprocket Assembly, 19 tooth (
See “Interplant Push Row Unit Drive (Style A)” on
)
25
GD11045
-
Lock Clamp
26
GD0914-106.5
GD0914-166.75
2
-
Hex Shaft, ⅞" x 106½" (No Holes), Wing, 12 Row 30"
Hex Shaft, ⅞" x 166¾" (No Holes), Wing, 16 Row 30"
27
GA2180
-
Hanger Bearing, ⅞" Hex Bore
28
G10130
G10923
-
-
Square Head Machine Bolt, 5∕16"-18 x 1¾"
Flange Nut, 5∕16"-18, No Serration
29
G10233
-
Machine Bushing, 1", 10 Gauge
30
GA7052
GR1557
GR1298
GR1297
GR1294
GR1293
-
-
-
-
-
-
U-Joint W/Grease Fitting, Female, 10¼" Long, 12 Row 30" And 16 Row 30"
Grease Fitting, 45°, Metric
Inboard Yoke And Outer Profile (18¼" U-Joint)
Inboard Yoke And Outer Profile (10¼" U-Joint)
Cross And Bearing Kit
Yoke, ⅞" Hex
31
GA7051
GR1557
GR1296
GR1295
GR1301
GR1294
GR1293
-
-
-
-
-
-
-
U-Joint W/Grease Fitting, Male, 12¼" Long
Grease Fitting, 45°, Metric
Inner Profile
Inboard Yoke
Spring Pin, 8 mm x 50 mm
Cross And Bearing Kit
Yoke, ⅞" Hex
32
GD0914-45
GD0914-35
GD0914-38
1
-
-
Hex Shaft, ⅞" x 45" (No Holes), R.H. Main Frame, 12 Row 30" and 16 Row 30"
Hex Shaft, ⅞" x 35" (No Holes), L.H. Main Frame, 12 Row 30" and 16 Row 30"
Hex Shaft, ⅞" x 38" (No Holes), L.H. Main Frame, 12 Row 30" and 16 Row 30"
33
G10004
G10229
G10101
2
2
-
Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
34
GD14426
1
Tightener Shaft, 3⅜"
35
GD14431
1
Handle
36
G11078
1
Vinyl Cap
37
G11100
G11453
1
1
Hex Socket Button Head Cap Screw, ¼"-20 x ½", Grade 8
Fender Washer, ¼"
38
G10235
1
Machine Bushing, ⅞", 14 Gauge
39
G10496
2
External Inverted Snap Ring, 1½"
40
G11075
2
External Inverted Snap Ring, ⅞"
41
GD14432
1
Sleeve, 1¼"
42
GD14414
GD14413
1
-
Torsion Spring, R.H. (Used In L.H. Wrap Spring Wrench)(Shown)
Torsion Spring, L.H. (Used In R.H. Wrap Spring Wrench)
43
GD19344
GD19343
-
1
Release Collar, Gray, L.H. (Shown)
Release Collar, Blue, R.H.
A
G1K269
-
Lock Clamp Kit (Items 25 And 28)
B
G1K381
G1K380
-
-
Wrap Spring Wrench Replacement Kit, Gray Collar, L.H. (Items 34-43) (Shown)
Wrap Spring Wrench Replacement Kit, Blue Collar, R.H. (Items 34-43)
