KPM III Electronic Seed Monitor
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA7858
-
Radar Distance Sensor W/20' Cable
2
GA8026
-
Radar Sensor Pipe/Mounting Bracket Package
3
G1K323
-
4-Pin Connector Kit W/Female Housing, Includes: (4) Pins, (1) Cable Clamp
4
GA5600
1
Magnetic Distance Sensor
5
GD8751
-
Magnetic Distance Sensor Pulse Wheel
6
GD6291
-
Insulated Clamp, ⅜"
7
GD8770
1
Bracket
8
G10001
G10229
G10101
2
2
2
Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
9
GD8771
1
Spring Wave Washer
10
GD18168
2
Mount
11
GA17547
1
Power Lead Adapter
12
GA9144
-
Monitor/Radar Adapter Cable, 10"
13
G1K267
-
Console Cable Connector Kit, Includes: (1) Cable Clamp, (1) 3-Pin Connector, (3)
Male Terminal Pins
14
G1K268
-
Console Cable Connector Kit, Includes: (1) Cable Clamp, (1) 3-Pin Connector, (1)
Lock Ring, (3) Female Terminal Pins
15
8647x
GA12403
GR1762
GA16082
-
-
-
-
KPM III Backlit Console W/Brush (Item 22), Dust Plug (Item 33), Console Mounting
Bracket Hardware And Power Harness
Mounting Bracket Assembly, Includes: (2) Mounting Brackets, (2) Connector Halves,
(1) Compression Spring, (1) Tension Knob, (1) ¼"-20 x 1¾" Hex Head Cap Screw,
(1) ¼" Plastic Washer, (1) ¼" Steel Washer
Console Mounting Bracket Hardware Package, Includes: (3) No. 10-32 x ⅝" Hex
Socket Pan Head Screws, (3) No. 10 Lock Washers
Power Harness
16
G1K322
-
4-Pin Connector Kit W/Male Housing, Includes: (4) Female Socket Contacts And (1)
Cable Clamp
17
---
-
See Tractor/Planter Wiring Harness, Items 18 And 39
18
GA7852
GD11993
-
-
Planter Harness W/Dust Caps (20 Connectors)
Dust Cap
19
GA19961
GA19960
-
-
Seed Tube W/Computerized Sensor
Seed Tube (With Holes For Sensor Installation)
20
GA7859
1
Magnetic Distance Sensor Adapter (Analog To Digital)
21
GD18118
2
Shaft Sensor Mount
22
GR0594
-
Brush
23
GR0586
1
Radar Y-Cable (Used To Connect Radar Distance Sensor For Multiple Functions)
24
GA7857
-
Adapter Harness, 1'
25
GA7854
GA7855
GD11993
-
-
-
Extension Harness W/Dust Cap, 15'
Extension Harness W/Dust Cap, 30'
Dust Cap
26
GA7853
GD11993
-
-
Junction Y-Harness W/Dust Cap
Dust Cap
27
G1K321
-
2-Pin Female Connector Kit (Black), Includes: (3) 2-Pin Female Housings, (6) Pin
Contacts, (6) Seals
28
G1K320
-
2-Pin Male Connector Kit (Black), Includes: (3) 2-Pin Male Housings, (6) Socket
Contacts, (6) Seals
29
G1K248
G1K362
-
-
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
3-Pin Female Connector Kit (Blue), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
Model 3600
M0236-02
Rev. 5/14
P198
