Rear Trailer Hitch, Conventional
ITEM PART NO. QTY. DESCRIPTION
1 GA6961 1 Hitch
2 G10007
G11391
G10230 4
4
4 Hex Head Cap Screw, ⅝"-11 x 1½"
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
3 G11396 2 Flat Washer, 1¼" SAE
4 GD3547
G10460 1
2 Pin, 1¼" x 12¾"
Cotter Pin, ¼" x 2"
5 GA6960 1 Hitch
6 GB0218 4 Bushing, 21∕32" I.D. x ⅞" O.D. x 19∕32" Long
7 GD7908 1 Tap Block
8 GB0213 1 Spring Seat
9 GD2115 1 Spring
10 GB0206 1 Rod Guide
11 GD7907
G10105 1
3 Special Bolt
Hex Nut, ¾"-10
12 G10826
G10396 5
5 Hex Head Cap Screw, 1"-8 x 2½"
Lock Nut, 1"-8
13 GD2721
G10228
G10102 2
4
4 U-Bolt, 2" x 2" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
14 GD10196 - Hanger Tube
15 GD0829 - Spring
16 G3305-03 - Twin Loop Chain, 15 Links
17 GA7209 - Hose Support
18 G10064
G11385
G10110 1
2
1 Hex Head Cap Screw, ¼"-20 x 1"
Flat Washer, ¼" SAE
Lock Nut, ¼"-20, Grade B
19 GA7208 - Hose Support
20 G10004
G10108 2
2 Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Nut, ⅜"-16
21 G4200-01 1 Hose, 1¼" x 22'
22 G10672 6 Hose Clamp, No. 28
23 G10626 1 Adapter, 1¼" NPT To Barb
24 GA4976
GR1015
GR1016
GR1017
GR1018
GR1019 1
-
-
-
-
-
Shutoff Valve, 1 ¼" NPT
Body O-Ring
Stem O-Ring
Teflon Seat
Ball
Handle
25 GD1514 1 Adapter, 1¼" Male NPT To Cam Lock
26 GD1515 1 Dust Cap, 1¼" Cam Lock
27 GD1516 1 Adapter, 1¼" Barb To Female Cam Lock
28 GD1517 1 Dust Plug, 1¼" Male Cam Lock
29 G10172
G10229
G10101 1
1
1 Hex Head Cap Screw, ⅜"-16 x 5"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
30 G10756
G10229
G10101 1
1
1 Hex Head Cap Screw, ⅜"-16 x 6"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
Model 3600 M0236-02
Rev. 7/11 P252
