Liquid Fertilizer Piston Pump Mount and Ground Drive Wheel
ITEM PART NO. QTY. DESCRIPTION
7 GA10621
G10641 1
2 Arm W/Grease Fittings
Grease Fitting, ⅛" NPT
8 GA0241 1 Wheel, 5" x 15"
9 GD1166 1 Valve Stem
10 G10012
G11391 1
1 Hex Head Cap Screw, ⅝"-11 x 6½"
Flat Washer, ⅝" SAE
11 GA10908 1 Spring Mount
12 GB0196 1 Washer
13 GD7831 1 Compression Spring
14 GA10907 1 Spring Guide
15 G11122
G10107 1
1 Hex Head Cap Screw, ⅝"-11 x 12"
Lock Nut, ⅝"-11
16 G10026
G10231 2
2 Hex Head Cap Screw, ¾"-10 x 2"
Lock Washer, ¾"
17 G11042
G10231
G10105 2
2
2 Hex Head Cap Screw, ¾"-10 x 1¾"
Lock Washer, ¾"
Hex Nut, ¾"-10
18 GD13744 1 Hose Holder
19 GR1146 1 Sprocket, 18 Tooth
20 G10003
GR1122
G11387
G10229
G10101
GR0200 4
4
8
4
4
1 Hex Head Cap Screw, ⅜"-16 x 1½"
Mounting Pad
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Nut, ⅜"-16
Offset Link, No. 2050
21 --- - See “Liquid Fertilizer Piston Pump (Uses 18 Tooth Sprocket)” on page P243
22 G10007
G11391
G10230
G10104 2
2
2
2 Hex Head Cap Screw, ⅝"-11 x 1½"
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
23 GA10894 1 Pump Mount
24 G10017
G11389
G10228
G10102 2
2
2
2 Hex Head Cap Screw, ½"-13 x 1½"
Flat Washer, ½" SAE
Lock Washer, ½"
Hex Nut, ½"-13
25 GD13328 1 Scraper
26 G10013
G11391
G10230
G10104 1
1
1
1 Hex Head Cap Screw, ⅝"-11 x 3½"
Flat Washer, ⅝" SAE
Lock Washer, ⅝"
Hex Nut, ⅝"-11
27 GA0262 1 Idler Sprocket W/Bearing, 15 Tooth
28 GD7817-05 1 Spacer, 11∕16" I.D. x 1¼" Long
29 GD0844 1 Tire, 7.60" x 15", 8 Ply (Specify Brand*)
30 GA2559 1 Spindle
31 GA0252 2 Seal
32 GA0251 2 Bearing
33 GR0267 5 Lug Nut, ½"-20
34 G2500-84 1 Sprocket, 48 Tooth
35 G10019
G10232 4
4 Hex Head Cap Screw, 5∕16"-18 x 1"
Lock Washer, 5∕16"
36 GD0831 2 Shoulder Nut, 1¼"-12 UNF-2A
37 GA0547
GR0190
GR0204 1
2
5 Hub W/Cups And Studs, 5 Bolt
Cup
Stud
38 G3200-63
GR0195
GR0200
-
-
`-
Chain, No. 2050, 63 Pitch Including Connector And Offset Link, Used With NGP-
7075 Piston Pump
Connector Link, No. 2050
Offset Link, No. 2050
39 GD2558 1 Lynch Pin, ¼"
* Specific brand requests will be supplied only as available from current Kinze Repair Parts stock. If a specific brand requested is not in
stock, the brand available will be supplied. Different brand tires may have different diameters. Change in tire brand may affect rates. Field
checks are recommended after any change in tires.
Model 3600 M0236-02
Rev. 7/11 P238
