Kinze 3600 Lift and Rotate Planter Rev. 5/14 - Manual (Page 157)

ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 GA13719
G10168
G10045
G10844
G10228
G10102 1
2
1
1
2
2 See “Row Marker Spindle/Hub/Blade” on page P157
Machine Bushing, ½", 7 Gauge
Hex Head Cap Screw, ½"-13 x 4½"
Carriage Bolt, ½"-13 x 3½"
Lock Washer, ½"
Hex Nut, ½"-13
2 GD0453-07
GD0453-03
GD0453-04
GD0453-08 1
-
-
-
Extension Tube, 45", 12 Row
Extension Tube, 50", 16 Row
Extension Tube, 60", 12 Row Even-Row
Extension Tube, 65", 16 Row Even-Row
3 GA13994
GA13114
G10643
GD2721
G10228
G10102 1
-
-
1
2
2
Arm, Third Stage, 12 Row
Arm, Third Stage, 16 Row
Grease Fitting, 45°, ¼
"-28
U-Bolt, 2" x 2" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
4 GD18889
G10460
G10345 1
2
2 Pin, 1" x 9¼"
Cotter Pin, ¼" x 2"
Machine Bushing, 1", 14 Gauge
5 GA9145
G10004
G11387
G10108 1
2
2
2 Molded Stop, 6¼" Long
Hex Head Cap Screw, ⅜"-16 x 1¼"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
6 GD18540
G10004
G10108 1
2
2 Lock-up Chain Bracket
Hex Head Cap Screw, ⅜"-16 x 1¼"
Lock Nut, ⅜"-16
7 GA13764
G11391
G10006
GB0218
G10107 1
2
2
2
2 Linkage
Flat Washer, ⅝" SAE
Hex Head Cap Screw, ⅝"-11 x 2¼"
Bushing, 21∕32" I.D. x ⅞" O.D. x 19∕32" Long
Lock Nut, ⅝"-11
8 GD25189
GD3180-34
GD10538-07
G10039
G10111 1
1
1
1
1 Marker Link
Sleeve, ⅞" O.D. x ⅝" I.D. x 2"
Sleeve, ¾" O.D. x ½" I.D. x .3⁄5"
Hex Head Cap Screw, ½"-13 x 1¾"
Lock Nut, ½"-13
9 G10036
G11391
G10107 1
2
1 Hex Head Cap Screw, ⅝"-11 x 4"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-11
10 GA17399
GA17400 1
-
Marker Link, 66¾", 12 Row
Marker Link, 113¼", 16 Row
11 G10033
GD19661-01
GD16418-02
G10111 1
1
2
1 Hex Head Cap Screw, ½"-13 x 3½"
Sleeve, ¾" O.D. x 51∕100 I.D. x 2"
Sleeve, 1⅛ O.D. x 13∕16" I.D. x 11∕25"
Lock Nut, ½"-13
12 GD18815
G10159
G10460 1
2
2 Pin, 1¼" x 8.38"
Washer, 1⅞"
Cotter Pin, ¼" x 2"
13 GA14632
G6801-08
GR1037
G6400-08-04
GR1465 1
1
-
1
-
See “Row Marker Cylinder” on page P159
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
Connector W/O-Ring, ¾"-16 Male JIC To 7∕16"-20 O-Ring
O-Ring
Row Marker Assembly
Model 3600 M0236-02
Rev. 5/14 P154
