Kinze 3600 Lift and Rotate Planter Rev. 5/14 - Manual (Page 81)

ASD Fan Hydraulic Components (EdgeVac)
ITEM PART NO. QTY. DESCRIPTION
1 G6801-12
GR1467 1
-
Elbow W/O-Ring, 90°, 11/16"-12 Male JIC To O-Ring
O-Ring
2 G6801-10-12
GR1037 1
-
Elbow W/O-Ring, 90°, ⅞"-14 Male JIC To 11/16"-12 O-Ring
O-Ring
3 *A12755 1 Hose Assembly, ½" x 44"
4 *A11447 1 Hose Assembly, ⅝" x 45"
5 *A8221 1 Hose Assembly, ½" x 76"
6 *A11445 1 Hose Assembly, ⅝" x 70"
7 *A3117 1 Hose Assembly, ⅜" x 176"
8 G6801-08
GR1037 4
-
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
9 *A12076 1 Hose Assembly, ⅜" x 165"
10 *A1464 2 Hose Assembly, ½" x 72"
11 *A11443 2 Hose Assembly, ⅝" x 73"
12 *A12754
*A8266 2
-
Hose Assembly, ½" x 206", 12 Row
Hose Assembly, ¾" x 268", 16 Row
13 *A11449
*A11450 2
-
Hose Assembly, ⅝" x 206", 12 Row
Hose Assembly, ⅝" x 266", 16 Row
14 *A12752 1 Hose Assembly, ½" x 23"
15 *A12085 1 Hose Assembly, ⅜" x 26"
16 *A3158 1 Hose Assembly, ⅜" x 46"
17 *A1021 1 Hose Assembly, ⅜" x 56"
18 *A11442
*A11458 1
-
Hose Assembly, ⅝" x 137½", 12 Row 30" and 16 Row 30"
Hose Assembly, ⅝" x 152", 16 Row 7.5" Twin Row
19 *A12751
*A12774 1
-
Hose Assembly, ½" x 142½", 12 Row 30" and 16 Row 30"
Hose Assembly, ½" x 157", 16 Row 7.5" Twin Row
20 *A12086
*A12087 1
-
Hose Assembly, ⅜" x 206", 12 Row
Hose Assembly, ⅜" x 266", 16 Row
21 G6801-06
GR1045 1
-
Elbow W/O-Ring, 90°, 9∕16"-18 Male JIC To O-Ring
O-Ring
22 *A12095 1 Hose Assembly, ⅜" x 80"
23 G6400-06
GR1045 1
-
Connector W/O-Ring, 9∕16"-18 Male JIC To O-Ring
O-Ring
24 *A12094 1 Hose Assembly, ⅜" x 73"
25 *A12096
*A15023 1
-
Hose Assembly, ⅜" x 140", 12 Row 30" and 16 Row 30"
Hose Assembly, ⅜" x 154", 16 Row 7.5" Twin Row
26 G306-06 1 Lock Nut, 9∕16"-18
27 G2700-06-06 1 Bulkhead Tube Union, 9∕16"-18 Male JIC
28 *A1424 1 Hose Assembly, ½" x 30"
29 *A3381 1 Hose Assembly, ¾" x 26"
30 *A12002 1 Hose Assembly, ⅜" x 32"
31 *A12753 1 Hose Assembly, ½" x 57"
32 *A11444 1 Hose Assembly, ⅝" x 59"
33 *A12093 1 Hose Assembly, ⅜" x 58"
34 G6602-06 1 Swivel Tee, 9∕16"-18 JIC
35 GA15499
GD25522 -
- Special Pioneer Coupler, Zero Pressure Return
Hydraulic Tip Cover
36 G4086 - ISO Coupler
* Hydraulic hose is not stocked by Kinze Repair Parts, but can be made available on a special order basis.
Call for quote.
Model 3600 M0236-02
Rev. 5/13 P78
