ITEM PART NO. QTY. DESCRIPTION
1 GA13299 1 Shroud
2 ---
G10599
G10229
G10101 -
2
2
2
See “Vacuum Fan Hydraulic Motor Assembly” on page P181
Carriage Bolt, ⅜"-16 x 1¼"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
3 GA14378
G10001
G11091 1
2
2 EdgeVac Fan Strut
Hex Head Cap Screw, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
4 GA11987
G10063
G11387
G10108 1
2
2
2 Screen
Hex Head Cap Screw, ⅜"-16 x 4"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
5 GA14396
G10001
G11091 1
4
4 Strut Mount
Hex Head Cap Screw, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
6 GD15789
G11133 1
6 Backing Plate
Hex Socket Head Cap Screw, 5∕16"-18 x ¾", Grade 8
7 GA10635 1 Impeller
8 GA14386
G10164
G11387
G10622 1
1
1
1 EdgeVac Fan Mount
Hex Head Cap Screw, ⅜"-16 x 2¼", Full Thread
Flat Washer, ⅜" SAE
Serrated Flange Nut, ⅜"-16
9 GD15790 1 Hub
10 G11391 1 Flat Washer, ⅝" SAE
11 G10499 1 Hex Jam Nut, ⅝"-18, Grade 2
12 GA13671 1 Fan Cover
13 G11124 6 Whiz Lock Bolt, ⅜"-18 x 1"
14 GD16839 1 Spacer, ½" x 12"
15 GD16992 1 Gasket, ⅛" x 11⅞"
16 GA13667
G11166 2
8 Snorkel Flange
Whiz Lock Bolt, ¼"-20 x ¾"
17 GD19460 2 Flange Seal, 4 Bolt
18 GA14387
G11204 1
4 Snorkel
Flanged Whiz Lock Screw, ⅜"-16 x 1¼", Serrated
19 GD19470 1 Flange Seal, 4 Bolt
20 GD19469
G11166 1
4 Snorkel Access Cover
Whiz Lock Bolt, ¼"-20 x ¾"
21 GD15863 1 Discharge Deflector
22 GA12812 - Hall Effect Adapter
23 GA14847
GD17151-20
GD16324-01
GA9964
G1K248 1
-
-
-
-
-
Low Pressure Sensor (0-40 IN H
2
0) (Replaces GA12811)
Tubing, ¼" x 10’, (Only with GA14847)
Clear Plastic Tubing, ¼" x 45"
Strain Relief
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
24 GR1736 1 Hose Barb, ⅛" Male NPT To Barb
25 GD21278 - Reducing Tee, 3∕16" x ⅛"
26 --- - See “Center Pivot” on page P119
27 GA10765
GR1777 2
-
Analog Vacuum Gauge W/Hose Barb
Hose Barb, 3∕16" x ⅛" NPT
28 GD15804
G10108
G10001 2
2
2 Mount
Lock Nut, ⅜"-16
Hex Head Cap Screw, ⅜"-16 x 1"
29 G11215 6 Hex Socket Head Cap Screw, No. 6-32 x ⅜", Grade 8
30 GD15849-02 1 Clear Tubing, 5∕16" O.D. x 3∕16" I.D. x 120"
31 GR1777 - Hose Barb, ⅛" Male NPT To 3∕16" Barb
32 GA10799 1 Breather, ⅛" Male NPT
Vacuum System
Model 3600 M0236-02
Rev. 5/14 P66
