CMS5000 Operating Manual
3 Each CMS5000 will have a unique IP address. An example of an IP address is
10.210.50.107. The subnet mask is also displayed on the NET page. An
example of a subnet mask is 255.252.0.0. See
Figure 4-11 .
Figure 4-11 NET Page
4 On the PC, click the Windows Explorer Start button. See Figure 4-12 .
Figure 4-12 Start
4a Mouse over Settings and click Network Connections. See Figure 4-13 .
Figure 4-13 Network Connections
