CMS5000 Operating Manual
12
To zoom out, click on Zoom Out icon. See
.
Alternately, press F11 to return to the full chromatogram.
Figure 12-56 Zoom Out Icon
Figure 12-57 Zoom Out
12.10 Range Tool
The Range Tool is used to reintegrate peaks and adjust the scan range.
1
Use the range tool to determine the scan range. The range tool is a red triangle
which is located at the left hand side of the screen. See
Figure 12-58
.
Figure 12-58 Range Tool
2
Click and drag the range tool underneath the x-axis until it is aligned with the
desired peak apex. See
Figure 12-59
.
