CMS5000 Operating Manual
3 The selected data file will be displayed in the Data Review screen, and the
filename will also be displayed under the Filename section in the Control
Panel. See
Figure 14-3 .
Figure 14-3 Data File in Control Panel
4 Click the button in the row below the data file, which is outlined in red in Figure
14-4 .
Figure 14-4 Selecting Another Data File
5 Follow steps 1-3 to select the second desired data file. The second data file will
appear in the second row. See
Figure 14-5 .
Figure 14-5 Second Data File
