Prepare for Installation
Installation Environment
• Dry room (30-95% humidity, non-condensing)
• 0-35°C (32-95°F) ambient temperature
• Dust free
• Wall-mounting location must support 23kg (50lbs)
• Minimum 25.4cm (10”) clearance in front of unit for airflow vents
Electrical Requirements
• 50-60Hz
• 230/400 VAC, 3Ø+N+PE 40A per phase
• 230 VAC, 1Ø+N+PE 120A per phase
• For use on TN-C, TN-S, TN-CS and TT supplies
• Not suitable for use on Delta IT supplies
• This equipment must be connected to a suitable safety earth/ground.
Cable Specification
Purpose Cable Type/Description Note
AC Input - Three phase
230/400 VAC 3Ø+N+PE,
50-60Hz, 40A per phase 25mm
2 / 2AWG maximum stranded
cable
Use only cables of size and rating
complying with local wiring regulations. Supply gauge must be coordinated
with upstream protective switchgear.
AC Input - Single phase
230 VAC, 1Ø+N+PE,
50-60Hz, 120A per
phase
DMX512
Recommended - Belden 9729
Alternatives
Carol - C0910
General -0E8990
Olfex - 9729
Omni - D62402
Quabbin - 8604
Olympic - 2998
Pro-Plex - PC224T
CAT 5 cable is also approved for
DMX distribution if installed in
grounded metal conduit.
• For use of CAT 5 cable, you will
need to purchase a CAT 5
termination kit (ETC part number
4100A1013) from a local ETC
office or service provider.
SmartLink™
Belden 8471 plus 1 - 2.50mm
2
ESD
drain wire recommended (drain wire not
required if installed in grounded metal
conduit).
For use with wall stations and
SmartLink pack to pack
synchronization. SmartLink is FTT-
10A topology-free and polarity
independent.
Emergency 2 - 1.5mm 2 twisted
Contact input for emergency lighting
loads.
