16 SmartPack Wall Mount Installation Manual
Final Installation and Power Up
Verify Installation
• Is the SmartPack unit securely mounted with all mounting bolts tight?
• Is there sufficient clearance 254mm (10”) in front of the unit?
• Check wiring:
• Are all power supply and load cables landed and properly terminated?
• Are all emergency lighting circuits separated from normal circuits with a voltage
barrier?
• Are all unused cable access openings covered with plugs or removable plates?
• Do all control cables meet specifications?
• Are all low voltage connections terminated properly?
• Are all data terminations terminated?
• Remove all debris and the debris shield from the unit.
• The SmartPack Wall Mount unit ships with a debris shield to protect the electronics
during installation. Leave this shield in place during installation and remove only
after installation is complete and before energization. If debris falls into the fan or
electronics remove the debris before applying power to the unit.
Final Installation
Step 1: Attach the ground wire with the ring terminal from the chassis to the grounding
stud on the I/O panel and secure.
Step 2: Close the I/O panel and secure with two screws.
a: All wires should be dressed neatly.
b: Ensure the wires are not crimped in the I/O Panel while closing.
Step 3: Attach the ground wire with the spade connector to the front cover and secure
the front cover to the unit.
Step 4: Apply power to the unit.
Test Loads via Menu
After power is applied to the unit, select the operating language and test each load using
the TEST MENU.
Select the operating language:
Step 1: Apply power to the unit. Available languages for SmartPack will scroll in the
display at 3-second intervals.
Step 2: Press when the preferred language is displayed:
•Set Language - English
•Choisir la langue - Français
•Sprache auswählen - Deutsch
•Seleccionar idioma - Español
