AVC
PORTS
• Video Output
Video output is via three BNC connectors. These connectors can be configured using
Designer to output either Composite (CV), S-Video (Y, C) or Component (Y, Pr, Pb).
The video output is taken from the output of an internal video mixer, the inputs to which
are the encoded video (uploaded using Designer) and the video input.
• Analog Audio Output
Balanced stereo audio output is provided @ 0dBV line level on a 6 way connector:
Balanced audio right channel +
Balanced audio right channel - (tie to ground for unbalanced)
Signal ground
Balanced audio left channel +
Balanced audio left channel - (tie to ground for unbalanced)
Signal ground
The analog audio output is taken from the output of an internal audio mixer, the inputs to
which are the encoded stereo audio (uploaded using Designer) and the analog audio input.
• Digital Audio Output
This port is not supported at the time of writing (refer to the current Designer Help).
• Video Input
Video input is via two BNC connectors. These connectors can be configured using
Designer to accept either Composite (CV) or S-Video (Y, C).
• Analog Audio Input
Balanced stereo audio input is provided @ 0dBV line level on a 6 way connector:
Balanced audio right channel +
Balanced audio right channel - (tie to ground for unbalanced)
Signal ground
Balanced audio left channel +
Balanced audio left channel - (tie to ground for unbalanced)
Signal ground
L
R
L
R
