ETC Unison Mosaic Show Control User Manual
Page 17
17
TPC
RESET SWITCH
The TPC may be reset by removing the magnetic overlay and pressing the reset switch. The
switch should be held for at least one second.
CONFIG SWITCH
The TPC may be placed in a configuration mode by removing the magnetic overlay and pressing
the config switch, refer to Designer Help for instructions.
WATCHDOG
An internal "watchdog" will automatically reset the TPC in case of a software crash as a result
of either a coding error ("bug") or a random electromagnetic event such as a power brown-out
or spike, nearby lightning strike or static discharge.
LEARNING IR RECEIVER
The TPC may be taught to recognise different IR codes from a standard infra red remote
control, refer to Designer Help for instructions.
NOTE:
The reset must not be operated during firmware updates to the TPC as
corruption of the software may occur, perhaps even rendering the unit
inoperable.
