Aluminum Mast
Light weight lower mast material.
Lengths:
3, 4, 5 & 6 m
(122
1
/
2
, 163
1
/
4
, 204 & 245 in.)
Inside diameter:
61.9 mm (2
7
/
16
in)
Outside diameter:
69.9 mm (2
3
/
4
in.)
Weight:
2.4 kg / meter
Available with or without mast base plate.
FRP Mast
Purpose designed Fiberglass Reinforced Plastic, manufactured from non-
hydroscopic epoxy and glass laminate, provides an insulated mast for
mounting the ERITECH
®
DYNASPHERE.
Lengths:
2 m (81
1
/
2
in.) & 4.6 m (187
3
/
4
in.)
Inside Diameter:
60 mm (2
3
/
8
in.)
Outside Diameter:
68 mm (2
11
/
16
in.)
Weight:
2 m = 3.3 kg (7
1
/
4
lbs.)
4.6 m = 7.6 kg (16
3
/
4
lbs.)
Color/Finish: Black
ERITECH
®
ERICORE Downconductor
Purpose designed cables, using a copper 50 mm
2
(1/0 AWG) main conductor
to safely convey the lightning energy to ground, while minimizing side
flashing.
Diameter: 36 mm (1
7
/
16
”)
Weight: 1.2 kg / m
13 oz / ft.
ERITECH
®
DYNASPHERE Enhanced Terminal
Capture point of the ERITECH
®
SYSTEM 3000. Initiates an upward leader
during storm conditions to attract lightning discharges over a greater
radius than conventional protection.
Height:
140 mm (5
1
/
2
in.)
Diameter:
255 mm (10 in.)
Weight:
2.8 kg (6 lbs.)
Color/Finish:
Brushed Stainless Steel
