ERICO CADDY ROD LOCK L-Bracket User Manual

Caddy rod lock l-bracket, Instruction sheet

(1) bolt, washer & nut

(washer under nut

on opposite side)

(2) 1/4" or M6

self drill screw

or tap screw

*VdS Approval G413038. Complies with VdS®
CEA 4001 (Guidelines for Sprinkler Systems)
Chapter 15.2.3 and shall be installed in
accordance with VdS CEA 4001.

Part

Number

Article

Number

Rod Size

CRLL37EG

N/A

3/8"

CRLLM10EG*

390012

M10

CRLLM8EG*

390011

(washer under nut

(1) lag screw

on opposite side)

(1) bolt, washer & nut

(2) 1/4" or M6

lag screws

All governing codes and regulations and those required by the job site must be observed.

All pipe supports, hangers, intermediate components and structural attachments must ONLY be used as described herein and are NEVER to be used for any

The customer is responsible for:

www.erico.com

CFS457_F

CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH, and LENTON are registered trademarks of ERICO International Corporation.

CADDY ROD LOCK L-Bracket

other purpose.

SAFETY INSTRUCTIONS:

NOTE: All load ratings are for static conditions and do not account for dynamic loading such as wind, water or seismic loads, unless otherwise noted.

a. Conformance to all governing codes.

Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.

1 OF 2

b. The integrity of structures to which the products are attached, including their capability of safely accepting the loads imposed, as evaluated by a qualified engineer.
c. Using appropriate industry standard hardware as noted above.

TECHNICAL SUPPORT:

INSTRUCTION SHEET

WARNING:

ERICO products shall be installed and used only as indicated in ERICO product instruction sheets and training materials. Instruction sheets are available at

www.erico.com and from your ERICO customer service representative.
ERICO products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.

All instructions must be completely followed to ensure proper and safe installation and performance.

Improper installation, misuse, misapplication or other failure to completely follow ERICO's instructions and warnings may cause product malfunction, property

damage, serious bodily injury and death.
Products that are manufactured using spring steel components shall be used only in a non-corrosive indoor environment.

FM is a registered certification mark of FM Approvals LLC, LTD.
UL is a registered trademark of UL LLC
VdS is a registered trademark of VdS Schadenverhütung GmbH

lbs

Concrete

1/2"

4" or DN100

700

3114

1/2" x 3" lag screw

4" or DN100

600

2669

1/2" bolt, nut, washer

4" or DN100

700

3114

1/4" x 1-1/2" lag screw

N/A

300

1334

Min. 16 Ga. [1.5mm] Steel

1/2" bolt, nut, washer

4" or DN100

700

3114

1/2" bolt, nut, washer

4" or DN100

700

3114

1/4" x 1" self drill or tap screw

4" or DN100

3-1/2" or DN90

700

3114

Min. 12 Ga. [3mm] Steel

1/4" x 1" self drill or tap screw

4" or DN100

700

3114

Concrete

M10

4" or DN100

700

3114

M10 x 80mm lag screw

2" or DN50

600

2669

M10 bolt, nut, washer

4" or DN100

700

3114

M6 x 40mm lag screw

N/A

300

1334

Min. 16 Ga. [1.5mm] Steel

M10 bolt, nut, washer

4" or DN100

700

3114

M10 bolt, nut, washer

4" or DN100

700

3114

M6 x 25mm self drill or tap screw

4" or DN100

3-1/2" or DN90

700

3114

Min. 12 Ga. [3mm] Steel

M6 x 25mm self drill or tap screw

4" or DN100

700

3114

Concrete

M10

N/A

500

2224

M10 x 80mm lag screw

N/A

500

2224

M10 bolt, nut, washer

N/A

500

2224

M6 x 40mm lag screw

N/A

300

1334

Min. 16 Ga. [1.5mm] Steel

M10 bolt, nut, washer

N/A

500

2224

Min. 14 Ga. [2mm] Steel

M6 x 25mm self drill or tap screw

N/A

500

2224

Max. FM®1951

pipe size (NPS)

UL2239/ MSS/ General

Min. 14 Ga. [2mm] Steel

Structure

Fastener Type

Fastener

Quantity

Max. UL®203

pipe size (NPS)

Wood

Part Number

(Article Number)

CRLL37EG

CRLLM10EG

(390012)

Min. 14 Ga. [2mm] Steel

Wood

CRLLM8EG

(390011)

Wood
