Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.

CADDY® ROD LOCK Strut Nut

www.erico.com

CFS500_A

INSTRUCTION SHEET

1 OF 2

© 2014 ERICO International Corporation.

TECHNICAL SUPPORT:

3/8", M8, M10

WARNING:

ERICO products shall be installed and used only as indicated in ERICO product instruction sheets and training materials. Instruction sheets are available at

1.

www.erico.com and from your ERICO customer service representative.
ERICO products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.

2.

All instructions must be completely followed to ensure proper and safe installation and performance.

3.

Improper installation, misuse, misapplication or other failure to completely follow ERICO's instructions and warnings may cause product malfunction, property

4.

damage, serious bodily injury and death.
Products that are manufactured using spring steel components shall be used only in a non-corrosive indoor environment.

5.

All pipe supports, hangers, intermediate components and structural attachments must ONLY be used as described herein and are NEVER to be used for any

6.

other purpose.

NOTE: All load ratings are for static conditions and do not account for dynamic loading such as wind, water or seismic loads, unless otherwise noted.

The customer is responsible for:
a. Conformance to all governing codes.
b. The integrity of structures to which the products are attached, including their capability of safely accepting the loads imposed, as evaluated by a qualified
engineer.
c. Using appropriate industry standard hardware as noted above.

SAFETY INSTRUCTIONS:
All governing codes and regulations and those required by the job site must be observed.

CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH, and LENTON are registered trademarks of ERICO International Corporation.

Rotation Only

Untighten
stem nut

Remove insert to allow the
Strut Nut to slide and
rotate in the slot of the strut

Configuration #2

CRLSSxxEG

Insert allows for the
Strut Nut to rotate in
the slot of the strut

Sliding and Rotation

Untighten
stem nut

Configuration #1

Strut Edge Distance Requirement

Min of 1" [25mm] @ both strut ends

9/16" or 14mm

CRLSLxxEG

Part Number

Article

Number

Rod Size

Strut Channel

Profile

Strut Channel

Thickness

Required strut

slot width*

Load Rating

CRLSL37EG

N/A

3/8"

A - Type

12 Ga

9/16"

1,500 lbs

CRLSS37EG

N/A

3/8"

C - Type

14 Ga

9/16"

900 lbs

1.5 mm

14 mm

3,400 N

2.0 mm

14 mm

4,000 N

2.5 mm

14 mm

4,900 N

1.5 mm

14 mm

3,400 N

2.0 mm

14 mm

4,000 N

2.5 mm

14 mm

4,900 N

1.5 mm

14 mm

3,400 N

2.0 mm

14 mm

4,000 N

2.5 mm

14 mm

6,200 N

1.5 mm

14 mm

3,400 N

2.0 mm

14 mm

4,000 N

2.5 mm

14 mm

6,200 N

* ERICO® offers CADDY® ERISTRUT having 14mm slot width.

CRLSLM10EG

390042

M10

A - Type

CRLSSM10EG

390044

M10

C - Type

CRLSLM8EG

390041

M8

A - Type

CRLSSM8EG

390043

M8

C - Type
