Installation, operation and maintenance manual 39, Photo 13: once the eritech, Figure 24. photo 14 – ERICO 3000 ERITECH SYSTEM User Manual
Page 41
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
39
www.erico.com
Photo 13: Once the ERITECH
®
DYNASPHERE has been
fitted to the termination coupling, ensure the locking
screw is tightened securely.
30 mm
(1
1
/
4
in.)
40 mm
(1
1
/
2
in.)
20 mm
(
3
/
4
in.)
Double Wrap Silicon Tape
Half Lapping Over Entire Length - Ensure Tape Covers Join in Coupling
Figure 24.
Photo 14.
