ocation Configuration Audio Unit L
The is configured as a cabin by default and so it is not necessary audio unit audio unit
to change the configuration. To use the in a room other than the lift cabin, audio unit
proceed as follows.
Procedure
Reconfigure the jumper on configuration jumper 12.
If there is poor access to the pins, you can remove the electronics cover. Slightly
loosen the four screws and shift the cover downwards. Now you can remove the
cover.
The first 4 pins serve for setting the
location (1 – cabin ceiling, 2 – audio unit
cabin, default, 3 – under the cabin, 4 – shaft bottom).
Configure the required changes as printed on the electronics cover.
If you have removed the cover, put it back in the original position and tighten the
screw.
