find all the searched items in the column. Use another filter to make your search more
precise and efficient. Having completed filtering, click Delete filter in the used columns
to delete all the active filters. If you did not delete the setting, the filtration settings
would keep active even upon the
logout and you would obtain filtration results
CU
instead of complete information in your next search.
Figure:
Filtration Setting Result
Logs
The
section helps you view the diagnostic reports included in the log files. No logs
Logs
are displayed upon the application launch. Download the current logs from a file or the
upon login.
CU
Logs – Basic
The
menu includes a table with necessary data. Use the checkboxes
Logs – Basic
below the table to select the table columns. Select the parameters to display the
required information: display/hide the timestamp, log level and log group. Click Auto
refresh to enable automatic screen update in selected time intervals. Press Read from
device to read the current logs from the
connected. The following items are
CU
displayed in the table: Timestamp, which defines the date/time in which the event was
captured, and Level and Source, which define the log type and source respectively.
Message includes the information itself. The State parameter above the table specifies
how many logs (rows) have been read and the log start/end time.
Tip
You can also click anywhere in the table with your right mouse button to
display the context menu and delete the active filters.
Tip
Each table row is equipped with a hint including parameter description for
convenience.
