10. Technical Parameters
This section describes the technical parameters of the product. 2N Lift8
®
Central unit
100–240 V; 50/60 Hz; 0.75 A; up to 60W Power supply:
Backup power supply: 1.3 Ah / 3 Ah Internal Lead Acid Battery
500 m Maximum distance between splitters:
PSTN / GSM / UMTS / VoIP Interface for connection with lift service centre:
Configuration and monitoring: Voice menu / USB / remote
Indicators: 5 LEDs, three-colour
300x170x72 mm, 2.7 kg Dimensions and weight:
Splitter
Power supply: 24 V from central unit or local
Capacity: 5 audio units + camera module
Maximum overall length of cable in shaft: 1000 m
Lift block pulse: Relay, both NO and NC contacts
Dimensions: 142x98x34mm
IO module
Power supply: 24 V from central unit or local
Capacity: 4 inputs + 4 outputs
Inputs: Galvanic isolation, 12–24 V AC or DC
Outputs: Relay, NO contacts, u7p to 250 V, 5 A
Dimensions: 142x98x34 mm
