Product description
Eppendorf
®
PlateReader AF2200
English (EN)
15
2.5
Fluorescence detection system
Abb. 2-2: Upper fluorescence detection system (fluorescence top reading)
Fig. 2-2:
Upper fluorescence detection system (fluorescence top reading)
PMT
MTP
flash
lamp
condensor
reference
diode
beam
splitter
emission
excitation
filter
filter
3
2
2
1
