28 FoamLogix 3.3 / 5.0 / 6.5 Installer / Operations Manual
p/n: 029-0021-68-0
2.10 CABLE HARNESS
For cable harness overviews, see Section “ 9 Plate Drawings,” beginning on
page 170. Also see Figure 2-6: “Power Connection Wire Harness” on page
28.
p/n: 113436 ...Control Head Harness, 10’ x 4’ (3.1 x 1.2 m)
10’ - Flow Sensor x 4’ - Motor Control
p/n: 113438 ...Control Head Harness, 10’ x 14’ (3.1 x 4.3 m)
10’ - Flow Sensor x 14’ - Motor Control
p/n: 113439 ...Control Head Harness, 15’ x 19’ (4.6 x 5.8 m)
15’ - Flow Sensor x 19’ - Motor Control
p/n: 113437 ...Control Head Harness, 32” x 5.5’ (0.81 x 1.7 m)
32” - Flow Sensor x 5.5’ - Motor Control
p/n: 113434 ...Single Tank Moto Control
p/n: 113435 ...Dual Tank Motor Control
p/n: 113437 ...Control Head Harness, 32” x 5.5’ (0.81 x 1.7 m)
32” - Flow Sensor x 5.5’ - Motor Control
p/n: 113437 ...Control Head Harness, 32” x 5.5’ (0.81 x 1.7 m)
32” - Flow Sensor x 5.5’ - Motor Control
Figure 2-6: Power Connection Wire Harness
