90 User Manual
♦
Alarms Handling
♦
Man OverBoard (MOB) to navigate back to a missing person or object
♦
Simulation Mode with cursor control
♦
Video Input option
TECHNICAL SPECIFICATIONS
♦
Power consumption
(with internal GPS)
: 1A max @ 12V
♦
Power consumption
(no external GPS connected)
: 0.9A max @ 12V
♦
Interface : NMEA0183
♦
Autopilot Interface : NMEA-0180, NMEA-0180/
CDX, NMEA-0183
♦
Video Input : PAL or NTSC video signals
automatically selected
♦
Display : Sun Light Viewable Color
LCD
(active area 7" wide)
♦
Display Resolution : 800 x 480 pixels
♦
Cartography : C-MAP B
Y
J
EPPESEN
DATA
MEDIA
♦
Operating temperature range : 32/131 °F (0/+55 °C)
♦
Memory : Non volatile
♦
Keyboard : Silicon rubber, backlight
♦
Weight : 1,1 Kg
When the package containing the chart plotter is opened for the first time after
purchase, please make sure that the following contents are present (if any item is
missing, please contact your local dealer):
♦
External bracket and I/O cable 1,5 mt/5.9 feet
♦
AUX IN I/O cable 1,5 mt/5.9 feet
♦
Video Input cable
♦
Chart plotter's protective cover
♦
Fuse 2 Amp. + fuseholder
♦
User Manual
♦
Flush mounting kit + cutting template
(STARFISH
E
)
♦
Smart DGPS WAAS Receiver with cable 15 mt/45 feet
(STARFISH
E
)
INSERTING/REMOVING PROCEDURE
Remove the front cover as explained in the following pictures. Hold the MEDIA by
the long inclined side so that you can see the C-MAP label. Gently push the MEDIA
into the slot; push the MEDIA in as far as it will go to hold fixed into the slot and
place the front cover again.
