104 User Manual
♦
Find Ports Services, Ports By Name, Ports By Distance, Tide Stations,
Wrecks, Obstructions, Cursor, POIs, Lakes By Name, Lakes Informa-
tions, Coordinates or User Points
♦
Display vessel's position, direction and Track
♦
Alarms Handling
♦
Man OverBoard (MOB) to navigate back to a missing person or object
♦
Simulation Mode with cursor control
♦
Video Input option
♦
Video Output option
TECHNICAL SPECIFICATIONS
♦
Power consumption : 3 A max, @ 12 V
♦
Interface : NMEA0183
♦
Autopilot Interface : NMEA-0180, NMEA-0180/CDX, NMEA-
0183
♦
Video Input : PAL or NTSC video signals automati-
cally selected
♦
Video Output : VGA compatible
♦
Display : TFT transmissive LCD
(active area 15")
♦
Display Resolution : 1024 x 768 pixels
♦
Cartography : C-MAP B
Y
J
EPPESEN
DATA MEDIA
♦
Operating temperature range : 32/131 °F (0/+55 °C)
♦
Memory : Internal non volatile for user data backup
♦
Keyboard : Silicon rubber, backlight
♦
Weight : 4,5 Kg
When the package containing the chart plotter is opened for the first time after
purchase, please make sure that the following contents are present (if any item is
missing, please contact your local dealer):
♦
External bracket and I/O cable 1,5 mt/5.9 feet
♦
AUX IN I/O cable 1,5 mt/5.9 feet (2 pcs)
♦
Video Input cable (2 pcs)
♦
Video Output cable
♦
Chart plotter's protective cover
♦
Fuse 5 Amp. + fuseholder
♦
User Manual
♦
Flush mounting kit + cutting template
♦
Smart DGPS WAAS Receiver with cable 15 mt/45 feet
INSERTING/REMOVING PROCEDURE
Inserting the MEDIA
Hold the MEDIA by the short inclined side so that you can see the C-MAP label.
Open the door, gently push the MEDIA into one of the two slots; push the MEDIA
in as far as it will go, then close the door to hold fixed into the slot.
