88 User Manual
Beacon Receiver Connection
BARRACUDA
I
GPS (Internal GPS Receiver)
RTCM 104 OUTPUT+
SIGNAL RETURN
DIFFERENTIAL BEACON RECEIVER
BLACK
RED
WHITE
GREEN
YELLOW
BROWN
GRAY
ORANGE
PINK
BLUE
GND/COMMON
POWER+ 10-35Vdc
INPUT 1+
COMMON
OUTPUT 1+
INPUT 2+
OUTPUT 2+
INPUT 3+
OUTPUT 3+
COMMON
QUICK DISCONNECT BRACKET CABLE
DESCRIPTION WIRE COLOR
FUNCTION
NOTE For BARRACUDA: To connect a Differential Beacon Receiver see previous
figure "GPS Connection BARRACUDA" (External Smart GPS Receiver) .
