85 User Manual
CHART PLOTTER DIMENSIONS
48.5mm [1.9”]
52.5mm
[2.1”]
94.5mm [3.7”]
118.5mm [4.7”]
203.5mm
[8
”]
86.5mm
[3.4”]
151mm
[5.9
”]
241mm [9.5”]
GRAY parts are present ONLY on chart plotter WITH GPS INTERNAL
154mm [6.1”]
177.8mm
[7”]
INSTALLATION AND REMOVING
100mm
[3.9"] 126mm
[5"]
115mm
[4.5”]
45mm
[1.8”]
GRAY parts are present ONLY on chart plotter WITH GPS INTERNAL
220mm
[8.7"]
211mm
[8.3"]
Flush mount installation for BARRACUDA and Bracket installation for BARRACUDA/BARRACUDA
I
GPS
