and/or Radar Plotting); SD (Sounder Depth). The selected Talker ID is applied to
all sentences sent by the chart plotter from all Ports.
To select the Talker ID follow the procedure:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"NMEA-0183 Output Talker ID" + [ENTER] + "II/GP/EC/RA/SD" + [ENTER]
STARFISH/STARFISH
E
/EXPLORER
3
/MARLIN/OYSTER:
External Signal
Sets the External Output:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"External Signal" + [ENTER]
Then choose your preferred setting among External Alarm (when activated, this
pin goes to GND level. It is used to command an external buzzer), External Power
(it is command switch for the Radar. It must be used in conjunction with the Radar
Junction box device) and Off.
Cable Wiring pages
This menu allows you select the Cable Wiring page preferred:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output"+ [ENTER] +
"Cable Wiring" + [ENTER]
Power I/O Cable Wiring : EXPLORER
3
/SEAHORSE/SEAHORSE
E
/MARLIN/OYSTER: Shows a window contain-
ing the Power I/O cable wiring.
GPS Cable Wiring
: EXPLORER
3
/SEAHORSE
E
/BARRACUDA/STARFISH
E
/MARLIN/OYSTER:
Shows a
window containing the GPS cable wiring.
AUX In I/O Cable Wiring : EXPLORER
3
/MARLIN/OYSTER:
Shows a window containing the AUX IN I/O cable
wiring.
NOTE
O
NLY
F
OR
BARRACUDA/BARRACUDAiGPS: After pressing [ENTER] a window
containing the cable wiring is shown.
Send/Receive Routes & Marks
Sets the desired port used for transferring User Points and Routes functions:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Send/Rec Rts & Mrks" + [ENTER] + "Port n" + [ENTER]
Where:
n = 1/2/3 for SEAHORSE/SEAHORSE
E
/BARRACUDA/BARRACUDA
I
GPS
n = 1/2/3/4/5 for EXPLORER
3
/MARLIN/OYSTER/STARFISH/STARFISH
E
3.7.2 C-Link menu
Select the Primary or Secondary Station (see the dedicated Chapter):
[MENU] + "Advanced Options" + [ENTER] + "C-Link" + [ENTER] + "Second-
ary Station/Primary Station" + [ENTER]
3.7.3 Fix & Compass menu
To handle the functions related to navigation and to set the reference heading
information such as bearing angles (True or Magnetic), the Magnetic Variation
source and to enter Compass Calibration values.
[MENU] + "Advanced Options" + [ENTER] + "Fix & Compass" + [ENTER]
Fix Correction
: Turns On/Off the Correction from the positioning system. If the new Correction is calculated,
but the Correction is not enabled, the ship's position is not changed.
Compute Correction : Corrects fixes from the positioning instrument. By placing the cursor on the ship's real position
and selecting this option, the error is calculated and internally memorized for appropriate
correction, but not applied.
Correction Offset
: Manual correction of fix position.
Static Navigation
: Sets up a threshold for the speed. When the speed received from the positioning device is
under that threshold, the chart plotter displays zero speed.
