59 User Manual
Fig. 3.10.3 - Example of Directory page
The Directory page allows to:
♦
Edit : to edit the fields of any existing entry in the Directory, Vessel
Name, MMSI number, contact and phone number press [E
DIT
]
♦
Add : to add a new entry to the Directory press [A
DD
]
♦
Delete : to delete the selected entry press [D
ELETE
]
♦
Delete All : to delete all entries in the page press [D
EL
A
LL
]
3.10.4 Quick Info on DSC Icons
Placing the cursor on the Distress Call or Position Request icon, the following
information is displayed:
♦
Vessel Name/MMSI Number
♦
Position
♦
Date and Time
♦
Distance and Bearing from current vessel's position
Pressing [ENTER] it is possible, by selecting "DELETE" deletes the DSC icon from
the DSC Log page, otherwise by selecting "DSC LOG" the DSC Log page is shown.
3.11 FISH FINDER
The chart plotter combined with the sonar performance of the Fish Finder is one
of the most advanced marine navigation system available.
To select the Fish Finder menu, first select one of the pages related to the Fish
Finder:
[MENU] + "Page" + [ENTER] + "Fish Finder" + [ENTER] + select the desired
page + [ENTER]
MARLIN/OYSTER:
[DATA] + "Fish Finder" + [ENTER] + select the desired page + [ENTER]
Once the Fish Finder page is selected, access the Fish Finder menu by pressing:
[MENU]
For more information see the specific User Manual.
NOTE The Fish Finder display page is available only if the Fish Finder is connected
and powered On.
BARRACUDA/BARRACUDA
I
GPS/STARFISH/STARFISH
E
/EXPLORER 3 /
MARLIN/OYSTER:
3.12 RADAR
The Radar consists of a scanner unit which illuminates targets with microwave
energy and then collects the echoes from those targets. The scanner unit includes
