XTCC
Virtual SCSI drives
The following is displayed:
Inquiry data
Vendor ID, product ID, product revision level, drive serial number.
Vendor ID and product ID can be selected during configuration.
Drive Status
Online, Offline, Read/Write
Check Condition:
Date and designation of the error condition that occurred last.
Reservation
The last 4 bytes of the WWPN of the host which reserves the drive
are displayed.
Medium Type:
(Only with a mounted volume); always corresponds to the emulated
volume type .
VSN Location
Mount point, file system and path to the map of the mounted volume
in the cache (external RAID) or Controller, Target, Slice, LUN,
Filesystem and Path for mapping the volume in the cache (internal
RAID).
Base Directory
(Only with a mounted volume); details on the cache area which the
volume occupies.
Depending on the operating status, some of the information listed above may not be
displayed.
