the largest variable only because the scale of the vertical axis is very large. To see the smaller
variables, uncheck the largest variable temporarily.
Note - SNMPv3: Depending on the READ VIEW access settings of the User Account Name used,
there is a possibility that some MIB variables will not be displayed in this table.
6.3.3 Select All Button
: checks all variables. Clicking this button causes all variables to be plotted on the chart.
6.3.4 Clear Button
: unchecks all variables.
6.3.5 Reverse Button
: flips the states of all checkboxes, that is, unchecks all variables currently selected and checks all
variables currently not selected.
Note - Displaying many variables at the same time imposes a load on system resources. If you
encounter delay or reduced system performance, reduce the number of variables displayed, or
increase the polling interval. To reduce the number of variables, uncheck some variables in the MIB
variable table. To increase the polling interval, click the Options tab and change the Polling Interval.
6 MIB Variable Window
