Allied Telesyn

AT-VIEW PLUS

DEVICE MANAGER

XXXXXX

Sample Index. A maximum of the 40 latest index numbers are displayed.

7.3.4.2 Sort

To sort table items, click a column title. When you click the column title, table items are sorted by
the column in ascending order. One more click sorts the items in descending order. To restore the
original order, click the Reset Table button.

7.3.4.3 Reset Table Button

: Reorders table items to their original order after sorting.

7.3.5 Plot Chart Tab

In the RMON History Plot Chart tab, RMON history information is displayed in a time-scaled
plotted graph. Data is updated at the polling interval. The horizontal axis holds a maximum of the 40
latest data values.

Topics:

•

Popup Display

PN 613-50664-00 Rev A

Page 107 of 127
