Allied Telesis AT-S63 - Manual (Page 99)

AT-S63 Management Software Web Browser Interface User’s Guide
Section I: Basic Operations 99
Deleting Unicast and Multicast MAC Addresses
To delete a static or dynamic unicast or multicast MAC address from the
switch, perform the following procedure:
1. From the Home page, select Configuration.
2. From the Configuration menu, select the Layer 2 option.
The Layer 2 page opens with the MAC Address tab selected by
default, as shown in Figure 23 on page 94.
3. Display the MAC addresses on the switch by selecting one of the
options. For instructions, refer to “Displaying the MAC Address Table”
on page 94.
4. Click the button next to the MAC address to be deleted from the
switch. You can only delete one address at a time.
Note
You cannot delete a switch’s MAC address, an STP BPDU MAC
address, or a broadcast address.
5. Click Remove.
The MAC address is deleted from the table.
6. To permanently save your changes, select the Save Config option in
the Configuration menu.
