Chapter 21: Port-based and Tagged VLANs
336 Secton V: Virtual LANs
Creating a New Port-Based or Tagged VLAN
To create a new port-based or tagged VLAN, perform the following
procedure:
1. From the Home page, select Configuration.
2. From the Configuration menu, select the Layer 2 option.
3. Select the VLAN tab.
The VLAN tab is shown in Figure 132.
Figure 132. VLAN Tab (Configuration)
Note
The Modify and Remove buttons are not shown in the tab if the only
VLAN on the switch is the Default_VLAN.
The VLAN Mode and Uplink Port options are explained in “Selecting a
VLAN Mode” on page 344.
