AT-S63 Management Software Web Browser Interface User’s Guide
Section I: Basic Operations
83
Possible settings are:
Auto-Negotiate: The port autonegotiates both speed and duplex mode.
This is the default.
10Mbps - Half Duplex
10Mbps - Full Duplex
100Mbps - Half Duplex
100Mbps - Full Duplex
1Gb - Full Duplex (Applies only to 1000Base SFP and GBIC modules.
This selection should not be used. An SFP or GBIC module should use
Auto-Negotiation to set its speed and duplex mode.)
Note
A 10/100/1000Base-T twisted pair port must be set to Auto-
Negotiation to operate at 1000 Mbps. You cannot manually configure
a 10/100/1000Base-T twisted pair port to 1000 Mbps.
MDI/MDIX Crossover
The wiring configuration of a twisted pair port. This parameter does not
apply to fiber optic ports. Possible settings are:
Auto - Sets the port to automatically configure itself as MDI or
MDIX, depending upon the end node. This is the default. This
setting is only available when a port is set to Auto-Negotiation.
MDI - Sets a port to MDI. This setting is only available when a
port’s speed and duplex mode are set manually.
MDIX - Sets a port to MDIX. This setting is only available when a
port’s speed and duplex mode are set manually.
Ingress Broadcast Filter
Use this parameter to configure a port to forward or discard ingress
broadcast packets. Possible settings are:
Enabled - The port discards ingress broadcast packets.
Disabled - The port forwards ingress broadcast packets. This is the
default setting.
Egress Broadcast Filter
Use this parameter to configure a port to forward or discard egress
broadcast packets. Possible settings are:
Enabled - The port discards egress broadcast packets.
Disabled - The port forwards egress broadcast packets. This is the
default setting.
