Chapter 1: Overview
42
Section I: Basic Operations
Figure 11. Moving from the Configure Terminal Mode to the Class Map
Mode with the CLASS-MAP Command
LINE CONSOLE 0 Command
You use this command to move from the Configure Terminal mode to the
Line Console mode to set the console timer, activate or deactivate remote
authentication of manager accounts, and set the baud rate of the terminal
port.
Figure 12. Moving from the Configure Terminal Mode to the Line Console
Mode with the LINE CONSOLE Command
SPANNING-TREE MST CONFIGURATION Command
You use this command to move from the Configure Terminal mode to the
Multiple Spanning Tree mode to create multiple spanning tree instances.
Figure 13. Moving from the Configure Terminal Mode to the Multiple
Spanning Tree Mode with the SPANNING-TREE MST CONFIGURATION
Command
POLICY-MAP Command
You use this command to move from the Configuration Terminal mode to
the Policy Map mode where flow groups are mapped to traffic classes for
Quality of Service policies.
Figure 14. Moving from the Configuration Terminal Mode to the Line
Console Mode with the LINE CONSOLE Command
awplus(config)# class-map 256
awplus(config-cmap)#
awplus(config)# line console 0
awplus(config-line)#
awplus(config)# spanning-tree mst configuration
awplus(config-mst)#
awplus(config)# policy-map 1
awplus(config-pmap)#
