Chapter 4: MAC Address Table
64 Section I: Basic Operations
4. After selecting an option, click the View button. Figure 17 shows an
example of unicast MAC addresses.
Figure 17. View MAC Addresses Window
The columns in the table are described in Table 10.
Table 10. View MAC Addresses Window
Column Definition
VLAN ID Displays the ID numbers of the VLANs of
the ports.
MAC Address Displays the static and dynamic MAC
addresses.
Port(s) Displays the ports where the addresses
were learned or assigned. The MAC
address with port “CPU” is the address of
the master switch.
Type Displays the address type as either static
or dynamic.
