Chapter 10: IGMP Snooping
124 Section II: Advanced Operations
Configuring IGMP Snooping
To configure IGMP snooping:
1. From the Home page, click the Configuration button.
2. From the Configuration menu, click the Multicast button to display the
IGMP tab, shown in Figure 36.
Figure 36. IGMP Tab
3. Configure the parameters, described in Table 19, as needed.
Table 19. IGMP Tab
Parameter Definition
Enable IGMP Snooping
Status Enables and disables IGMP snooping on
the stack. A check in the box indicates
that IGMP snooping is enabled.
Multicast Host Topology Defines whether there is only one host
node per port or multiple host nodes per
port. Possible settings are Edge (Single-
Host/Port) and Intermediate (Multi-Host/
Port).
