Chapter 9: Event Logs and the Syslog Client
112 Section II: Advanced Operations
An example of the Full mode is shown in Figure 32.
Figure 32. Event Log Example Displayed in Full Mode
The columns in the tables are described in Table 17:
Table 17. Event Log
Column Definition
Severity Displays the event’s severity, which can
be one of the following:
E - Error - Switch operation is severely
impaired.
W - Warning - An issue that may require
network manager attention.
I - Informational - Information that can be
ignored during normal operation.
D - Debug - Messages intended for
technical support and software
development.
Date and Time The date and time of the event.
Event This item contains two parts. The first is
the name of the AT-S63 module that
generated the event. The second is a
description of the event.
Event ID (full mode only) A unique, random number assigned to
each event.
