AT-S63 Management Software Web Browser User’s Guide
Secton V: Virtual LANs 211
Note
Do not change the VLAN Mode parameter from User Configured.
Although the AT-9400 Switches can support a variety of VLAN
modes when they are used as stand-alone units, when assembled
into a stack they only support just that mode. Furthermore, do not
enter a value for the Uplink Port parameter because it is not used in
the User Configured mode.
The VLAN List section of the tab lists the VLANs in the stack:
Table 38. VLAN Tab
Column Definition
VID ID Displays the ID numbers of the VLANs.
(Client) Name Displays the names of the VLANs.
Uplink Port Displays “NA,” for Not Applicable, for port-
based and tagged VLANs, which are the
only type of VLANs supported by a stack.
Type Displays “Port Based” for port-based and
tagged VLANs.
Protocol Displays “None” for port-based and
tagged VLANs.
Member Ports Displays the untagged and tagged ports
of the VLANs. The untagged ports of a
VLAN are listed as follows.
Configured: The untagged ports that were
assigned to the VLAN when it was
created or last modified.
Actual: The current untagged ports of the
VLAN. If you are not using 802.1x Port-
based Network Access Control, the
Configured and Actual untagged ports of
a VLAN will always be the same.
