InfraStruXure Power Generation System 77
Specifications
Smart Distribution Panel with ATS
Electrical
Current Rating 250 A
Voltage Class 480 VAC
Voltage Available 208/120 Wye, 480 Delta, 480 Wye
Maximum Power 208 kW
Frequency 50/60 Hz Nominal, ±5 Hz
Interrupting Rating 35 kAIC
ATS Main Protection Magnetic fixed
ATS Switched Poles Three
EPO connection Dry contact and 24 VDC
EPO operation Disconnects all outputs
Output Distribution MCCB ABB Tmax T1 and T3 up to 225 A
Output Poles Three
Output Breaker Max Ampacity 225 A
Length of Breaker Bus Section 10.2 in/260 mm
Number of 100A Breaker Frames Six T1 3-Pole
‡
Number of 225A Breaker Frames Four T3 3-Pole
‡
Output Distribution Protection Type Thermal Magnetic
Physical
Dimensions
Height 75.0 in/1905 mm
Width 28.0 in/711 mm
Depth 14.5 in/368 mm
Weight 482 lb/218 kg
Shipping Dimensions
Height 81.0 in/2057 mm
Width 34.0 in/864 mm
Depth 34.0 in/864 mm
Maximum Shipping Weight 482 lb/219 kg
Cooling Natural convection
Enclosure NEMA 1 with drip protection; Raven black
Access Control Key-locked door and fastener-locked deadfront, user-removable
cover for user keypad/display and password
