Parts and tools needed for installation procedures – American Power Conversion 250 A User Manual
Page 83
How to Add Sub-Feed Output Distribution Circuit Breakers to the ATS
InfraStruXure Power Generation System
73
Parts and tools needed for installation procedures
All assembly parts needed for installation procedures are included with the circuit breaker kits.
T1 single-pole breaker assembly
T1 single-pole
T1 single-pole breakers
M3×75 screws, washers and retainers
Breaker brackets
M6×12 Torx screws
M4×15 screws and washers
T1 three-pole
T1 three-pole breakers
M4×70 screws and washers
Breaker brackets
M6 x 12 Torx screws
M4×70 screws and washers
Tools required
Phillips screwdriver
T25 Torx driver
Allen wrench
T1 three-pole breaker assembly
adapter module
T3 three-pole
T3 three-pole breakers
M4×70 screws and washers
Breaker brackets
M6 x 12 Torx screws
M4×70 screws and washers
T3 three-pole breaker assembly
adapter module
adapter module
