How to Add Sub-Feed Output Distribution Circuit Breakers to the ATS
70 InfraStruXure Power Generation System
Allowed circuit breaker combinations
The panel bus on your ATS allows a variety of circuit breaker combinations. Use the following
information as a guide in determining your circuit breaker combination.
Combination #1.
Combination #2.
Combination #3.
Combination #4.
Combination #5.
Type of Breaker # of Modules # of Breakers Space Occupied Space Remaining
T3 3-pole 2 4 8.26 in (209.8 mm) 1.94 in (49.6 mm)
T1 3-pole 0 0 0 1.94 in (49.6 mm)
T1 1-pole 1 2 1.00 in (25.4 mm) 0.94 in (24.2 mm)
Type of Breaker # of Modules # of Breakers Space Occupied Space Remaining
T3 3-pole 1 2 4.12 in (104.9 mm) 6.08 in (154.5 mm)
T1 3-pole 2 4 6.00 in (152.4 mm) 0.08 in (2.1 mm)
T1 1-pole 0 0 0 0.08 in (2.1 mm)
Type of Breaker # of Modules # of Breakers Space Occupied Space Remaining
T3 3-pole 0 0 0 10.2 in (259.4 mm)
T1 3-pole 3 6 9.00 in (228.6 mm) 1.2 in (30.8 mm)
T1 1-pole 1 2 1.00 in (2.54 mm) 0.2 in (5.4 mm)
Type of Breaker # of Modules # of Breakers Space Occupied Space Remaining
T3 3-pole 0 0 0 10.2 in (259.4 mm)
T1 3-pole 3 6 9.00 in (228.6 mm) 1.2 in (30.8 mm)
T1 1-pole 0 0 0 1.2 in (30.8 mm)
Type of Breaker # of Modules # of Breakers Space Occupied Space Remaining
T3 3-pole 0 0 0 10.2 in (259.4 mm)
T1 3-pole 2 4 6.00 in (152.4 mm) 4.2 in (107.0 mm)
T1 1-pole 4 8 4.00 in (101.6 mm) 0.2 in (5.4 mm)
